- Brand Name: YET
- Model Number: yet 402 PC-JY
- name: mc remote shutter door receiver
- working volg: dc 12v
- working temp: -40℃ - +80℃
- working frequency: 315 mhz 433 mhz
- max store of transmitter: 30 pcs learning code or fixed code
- staies woreking current: ≤7mA
- receive sensitivity: ≥-105dBm
- contact current: ≤10A
- size: 74.5mm*54.5mm*27mm
- Motor over-current protection threshold: mc dc 12 v control door motor 433
Packaging & Delivery
|Packaging Details:||500 pcs /box|
|Delivery Detail:||5-7 days|
Specificationsmc dc 12 v control door motor 433
1.woreking voltg :12v dc
mc dc 12 v control door motor 433
produced YET402PC-JY (Road Wireless Intelligent receiver controller), through the intelligent handling internal circuitry to achieve DC motor, reverse the motor control and automatic overload protection. Mainly used in electric doors, windows, gateways, lifts and security industries.
The wireless receiver controller with high security, large memory capacity, stable performance, low power consumption features, and easy to use, without using the traditional jumper or DIP switch coding, just the wireless signal emitted by the remote control so that The receiver controller receives and stores, supporting the use can be realized. If you learn good remote control is lost during use, simply receiving the information stored in the controller cleared the lost remote control will not be able to receive the remote controller, the desire to regain the right to use must be made by the owner again relearn once before use.
the method of learning and clear codes and procedures
Press the learning button on the controller until the LED lights lit release the button to learn, the controller enters the learning state (the LED is off), and then press the need to control the controller's remote control button, when you see the controller LED lights flash five times off, said it had success in learning. Up to 30 can learn the type of remote control button.
If the remote control is lost, purports to remote control all the failures, you should press the button to learn (more than 8S), pending the LED light is off, the controller will automatically clear the memory contents. To re-use, just learning once again.
the motor overcurrent
The motor is running, real-time monitoring of the motor controller will run the state. If the motor is running so that it encountered hinder current suddenly increases and reaches a certain limit, the controller will automatically shut down the motor, and the motor to achieve the personal and property protection. Current limit protection through an adjustable resistor can be adjusted on the controller clockwise adjustment knob, adjustable resistor current protection limit increases; adjustable resistance knob counterclockwise to adjust the current limit protection is reduced.
1.Accept OEM, ODM.
2.Print logo on the case and pakage
3.Payment Details: 30%deposite,70%balance before shipment.Payment accept T/T and western union optional.
4.Minimum Order: 100 pcs(accept trial order)
5.Delivery Details: within two weeks.
1.Your inquiry related to our products or prices will be replied in 12 hours
2.Well-trained and experienced staffs to answer all your enquires in fluent English
3.OEM&ODM, any your customized products we can help you to design and put into production
4.Protection of your sales area, ideas of design and all your private information
5.Deliver by air mail or ship for your orders
